Teknik Özellikler
Specifications
|
Function |
Range |
Display Scope |
Resolution |
Operation Condition |
|
V(BR) |
1000V |
0-1999V |
1V |
breakdown current < 1mA |
|
200V |
0-199.9V |
0.1V |
breakdown current < 1mA |
|
|
VCC(Set) |
2A(Ic) |
0-6.00V |
0.01V |
Ic≈2000mA Ib≈200mA |
|
800mA(Ic) |
0-6.00V |
0.01V |
Ic≈800mA Ib≈80mA |
|
|
100mA(Ic) |
0-6.00V |
0.01V |
Ic≈100mA Ib≈1mA |
|
|
10mA(Ic) |
0-6.00V |
0.01V |
Ic≈10mA Ib≈1mA |
|
|
hFE |
10mA(Ib) |
0-199.9 |
0.1 |
Ib≈10mA |
|
1mA(Ib) |
0-1999 |
1 |
Ib≈1mA |
|
|
1µA(Ib) |
0-1999 |
1 |
Ib≈0.01mA |
|
|
ICEO |
2000µA |
0-1999µA |
1µA |
Vce ≈ 27V |
|
78,79 three-pole constant voltage value |
78xx/79xx |
0-24.0V |
0.1V |
Ui ≈ 27V |
