Teknik Özellikler
|
Model |
ENS12/24-20D |
ENS12/24-30D |
ENS12/24-40D |
ENS12/24-50D |
ENS12/24-60D |
|
Normal voltage |
12/24V, automatic recognition |
||||
|
Nominal battery charge current |
20A |
30A |
40A |
50A |
60A |
|
Max. PV input power |
300W@12V 600W@24V |
450W@12V 900W@24V |
600W@12V 1200W@24V |
750W@12V 1500W@24V |
900W@12V 1800W@24V |
|
Max.solar input voltage Voc |
＜30V/48V |
||||
|
Min.solar input voltage Vmp |
＞16V/32V |
||||
|
Power conversion efficiency |
Max. 90% |
||||
|
Standby power consumption |
＜15mA |
＜15mA |
＜20mA |
＜20mA |
＜20mA |
|
Length≤1m charge loop drop |
<0.25V
|
||||
|
Length≤1m discharge loop drop |
<0.05V
|
||||
|
Temperature compensation |
-3 mv/cell *K |
||||
|
LCD screen display |
Battery voltage, PV charge current, Load discharge current, total PV charge Ah, total PV discharge Ah, the setting of constant voltage charging, the setting of low voltage disconnect, the setting of low voltage reconnect |
||||
|
Buttons |
Menu, Load( on/off), Up, Down |
||||
|
Dimensions |
172*126.3*73mm(L*W*H) |
||||
|
Weight |
0.4kg |
0.42kg |
0.45kg |
0.5kg |
0.55kg |
|
Ambient temperature range |
-40 to +50℃ |
||||
|
Case protection |
IP22 |
||||
|
Float charge |
13.8V/27.6V |
||||
|
Constant voltage charge |
14.6V( 14~15V settable )29.2V (28~30V settable) |
||||
|
Low disconnect voltage |
11V( 10.4~11.4V settable)/ 22V( 20.8~22.8V settable) |
||||
|
Low reconnect voltage |
12.8V( 12.2~13.2V settable)/ 25.6V( 24.4~26.4V settable) |
||||
|
Grounding |
Positive grounding |
||||
|
Battery type |
GEL,AGM, Solar battery etc. |
||||
