Teknik Özellikler
|
Specification |
Range |
Accuracy |
|
|
|
MS2015B |
|
DC Voltage |
60mV/600mV/6V/60V/600V |
|
|
600mV/6.6V/66V/660V |
±(0.5% +3) |
|
|
1000V |
±(0.8% +2) |
|
|
AC Voltage |
60mV/600mV/6V/60V/600V |
|
|
600mV/6.6V/66V/660V |
±(0.8% +3) |
|
|
750V |
±(1% +4) |
|
|
AC Current |
60A/600A/1000A |
|
|
66A/660A/1000A |
±(2.0% +3) |
|
|
Resistance (Ohm) |
600/6K/60K/600K/6M |
|
|
60M |
|
|
|
660/6.6K/66K/660K/6.6M |
±(1.0% +3) |
|
|
66M |
±(1.5% +3) |
|
|
Capacitance |
10nF/100nF/1000nF/10µF/ 100µF/1000µF/10mF/100mF |
|
|
6.6nF/66nF/660nF/6.6µF/ 66µF/660µF/6.6mF/66mF |
±(4.0% +3) |
|
|
Frequency (From Clamp) |
0~10KHz |
±(1.5% +5) |
|
Frequency (AC Voltage) |
0~10KHz |
±(1.5% +5) |
|
Logic Frequency |
0~60MHz |
|
|
0~66MHz |
±(0.5% +3) |
|
|
Duty Cycle |
10%~90% |
±3.0% |
|
Temperature (℃) |
-20℃~1000℃ |
±(2% +2) |
|
Temperature (℉) |
-4℉~1832℉ |
±(2% +4) |
