SPECIFICATIONS
| Feature | UTD1025C |
|---|---|
| Bandwidth | 25 MHz |
| Rise Time | ≤14 ns |
| Real-time Sampling Rate | 125MS/s |
| Equivalent Sampling Range | 25GS/s |
| Vertical Sensitivity | 5mV ~ 50V/div |
| Record Length (Max) | 2 x 512k |
| Scan Time Base | 10ns ~ 50s/div |
| Trigger Type | Edge, Pulse, Video and Alternate |
| Automatic Waveform Measurements | 27 |
| Frequency Counter | 6 digits frequency counter |
| Ports | USB Host |
| Mathematics | Add, Subtract, Multiply, Divide, FFT |
| Interface | Colour and Mono display selectable |
| Power | The provided battery or out-sourced adaptor |
| Life of Battery | 4 hours |
| Other Features | Multimeter,special LCD copy feature |
| Multimeter | |
| Resistance | 600Ω / 6MΩ / 60MΩ : ± (1.5% + 5 digits) 6kΩ / 60kΩ / 600kΩ : ± (1.2% + 5 digits) |
| DC Voltage | 600mV, 6V, 60V, 600V, 1000V: ± (1% + 5 digits) |
| AC Voltage (45Hz ~ 400Hz) |
600mV, 6V, 60V, 600V, 700V: ± (1.2% + 5 digits), Frequency: <200Hz ± (1.5% + 5 digits), Frequency: ≥200Hz |
| DC Current | 6mA, 60mA, 600mA: ± (1.2% + 5 digits) 6A: ± (1.5% + 5 digits) |
| AC Current (45Hz ~ 400Hz) |
6mA, 60mA, 600mA: ± (2% + 5 digits) 6A: ± (2.5% + 5 digits) |
| Capacitance | 6nF, 6mF: ± (5% + 10 digits) 60nF, 600nF, 6μF, 60μF, 600μF: ± (1.5% + 5 digits) |
| Continuity Buzzer |  |
| Diode | |
| Trend Diagram | |
| Testing Mode | Manual / Auto ranging |
| Max.Display | 5999 |
GENERAL CHARACTERISTICS
| Power | 100 - 240V 50/60Hz 1.5A |
| LCD Size | Diagonal 145mm (5.7 inches) |
| Product Color | Red and Grey |
| Product Net Weight | 1.8kg |
| Product Size | 268mm x 168mm x 60mm |
| Accessories | Probe x 2 (1x, 10x switchable), Current Voltage Convertor x 2(UT-M03, UT-M04) Power Cord, DC Adaptor and English Manual, Test Lead |
| Standard Individual Packing |
Tool Box and Gift Box |
| Standard Quantity Per Carton | 4 pcs |
| Standard Carton Measurement | 475 x 460 x 380mm (0.10 CBM Per Export Carton) |
| Standard Carton Gross Weight | Around 23.2kg |
