Teknik Bilgiler
| Frequency range | 1Hz - 3MHz |
| Frequency accuracy | ± (5×10-5 +10MHz + 1) |
| Output wave | Sine wave , square wave distortion |
| Harmonic distortion | -40dBс |
| Square wave distortion | 20ns |
| Function output impedance | 50Ω |
| Output amplitude | 16Vp-p |
| DC deflexion | ±6.4V |
| Inside amplitude modulating frequency | 400Hz, 1kHz |
| Inside amplitude modulating depth | 1%~100% |
| Outside amplitude signal frequency response | 100Hz~100kHz |
| Outside amplitude modulating input impedance | 600Ω |
| Frequency sweep time | 0.02s~5s |
| Outside frequency measurement sensitivity | 250mVrms |
| Dimension | 270 ×215 ×100mm |
| Weight | 1.9kg |
| Power | AC 220V/110V 50Hz/60Hz |
