AC Current
|
Range |
Resolution |
Accuracy |
|
AC 4A |
0.001A |
+/- (3.0% + 10) |
|
AC 40A |
0.01A |
+/- (2.5% + 10) |
|
AC 400A |
0.1A |
+/- (2.5% + 10) |
|
AC 600A |
1A |
+/- (1.5% + 5) |
-
DC / AC Voltage
|
Range |
Resolution |
Accuracy |
|
DC 400mV(MIN) |
0.1mV |
+/-(0.8%+3) |
|
AC 400mV(MIN) |
0.1mV |
+/-(1.5%+10) |
|
DC 600V(MAX) |
1V |
+/-(1.0%+3) |
|
AC 600V(MAX) |
1V |
|
-
Resistance
|
Range |
Resolution |
Accuracy |
|
400ohm |
0.1ohm |
+/-(1.2%+3) |
|
4kohm |
0.001kohm |
+/-(1.2%+3) |
|
40kohm |
0.01kohm |
+/-(1.2%+3) |
|
400kohm |
0.1kohm |
+/-(1.2%+3) |
|
4Mohm |
0.001Mohm |
+/-(1.2%+3) |
|
40Mohm |
0.01Mohm |
+/-(2.0%+5) |
-
Capacitance
|
Range |
Resolution |
Accuracy |
|
5nF |
0.001nF |
+/-(3.0%+10) |
|
50nF |
0.01nF |
+/-(3.0%+10) |
|
500nF |
0.1nF |
+/-(3.0%+10) |
|
5uF |
0.001uF |
+/-(3.0%+10) |
|
50uF |
0.01uF |
+/-(3.0%+10) |
|
200uF |
0.1uF |
+/-(3.0%+10) |
